How to Make a Silicone Mold

Want to cast your own concrete vessels, wax shapes, or embeds? A homemade silicone mold starts with a two-part silicone kit and an afternoon.

What you’ll need

Two-part platinum-cure silicone kit (1:1 mix by weight — use a digital scale)
An original — the object you want to copy
Mold box — LEGO bricks, foam board, or acrylic sheets
Hot glue gun to seal the box seams
Non-sulfur modeling clay to secure the original
Mold release spray (for porous originals)
Mixing cups, stir sticks, and a scale

The #1 silicone killer: Platinum-cure silicone will NOT cure if it touches latex, sulfur, or tin-cure silicone. Use nitrile gloves (not latex), non-sulfur clay, and keep tin-cure projects far away.

Steps

1. Build the mold box

Assemble a box around your original with at least 1/2 inch of clearance on all sides and the top. Seal every seam with hot glue — silicone finds leaks you can’t see. Stick the original to the base with clay so it can’t float.

2. Prep the original

If your original is porous (wood, plaster, 3D print), give it a coat of mold release or sealant. Smooth non-porous originals (glass, glazed ceramic, resin) usually need nothing.

3. Measure and mix

Measure equal parts A and B by weight. Mix slowly but thoroughly for 3 full minutes, scraping the sides and bottom — unmixed streaks stay gooey forever. Avoid whipping air in.

4. Pour

Pour in a thin stream from 6–12 inches above the box, aiming at one corner and letting the silicone flow over the original. The thin stream stretches and pops most bubbles on the way down.

Tip: If you have a vacuum chamber or pressure pot, now’s the time. If not, the thin-stream pour plus tapping the box gets you 90% of the way there.

5. Cure

Leave it alone for the full cure time — usually 16–24 hours at room temperature. Don’t poke it early; a dent made at hour 6 is permanent.

6. Demold

Take the box apart and peel the silicone away from the original. If you made a two-sided mold, cut along your parting line with a sharp blade using a zigzag cut so the halves register back together.

7. First cast

Wash the mold with dish soap and water, let it dry, and do a test cast. For candle wax, check your silicone’s max temperature rating before committing to a big batch.

Tip: Pair this with our concrete vessel tutorial — custom silicone molds are how you get vessels in shapes nobody else has.
